Stainless Steel Welded or ERW Pipe Manufacturers, Suppliers, Stockist – SS 304 Welded/ERW Pipes, SS 316 Welded/ERW Pipes, Duplex Welded Pipe Manufacturers
- As Metallica, we can produce and supply stainless steel pipes in both welded and seamless form. Stainless steel welded pipes are generally produced in specification ASTM A358 and ASTM A312. Metallica makes it easy for you to source top quality stainless steel welded pipes at the lowest prices in India. We specialize in providing fast deliveries to your factory directly from our warehouse or our principal suppliers.
- ASTM A-312 stainless steel welded pipe is more commonly found from 1/8″ NPS to and including 24” NPS in standard schedules 5, 10, 20, and 40. On special applications, sizes can be produced to 60” lPS through schedule 80 walls by certain mills.
- ASTM A-358 is usually produced in sizes 8” IPS and larger and where filler metal is added to the weld. This specification covers five classes of pipe and are usually determined by the end application and needs of the pipe.
- Manufacturing ASTM A-312 Standard Stainless Steel Welded Pipes – Pipe through 16” NB is manufactured by the continuous welding process and is very similar to welded tubing. Coils of flat roll strips are fed into sizing rolls and welded. Material is then annealed (usually in an open air furnace), straightened, cut, pickled, tested, and inspected. In full finished pipe, material is cold worked after welding. This can be done by rolling, forging, or drawing the weld bead; but primarily the weld is rolled.
- Manufacturing ASTM A358 Standard Stainless Steel Welded Pipes – Pipe 8” NB and larger is manufactured by the batch method or process. Unlike the continuous welding method stainless steel pipe made by this batch method is made in single lengths. Plates, cut to length and width, are formed from flat into tubular shape by a press and welded. Material is then annealed, sized, and straightened, ends trimmed or cut to specific smaller lengths, pickled, and inspected.
- All our stainless steel welded pipes and tube products are supplied with 3.1 specific test certificates, according to EN 10204. Certification according to 3.2 can be agreed at the time of ordering.
Stock & Production Range of Stainless Steel Welded Pipes
|Product||Stainless Steel Welded Pipes|
|Pipe Standards||ASTM A213, ASTM A312, ASTM A269, ASTM A778, ASTM A789, A554|
|Grades||304/L, 316/L, 201, 202, 301, 347/H, 316Ti, 309S, 310S, Duplex, Super Duplex, 904L, 317L|
|OD||6mm – 610mm OD|
|Thickness||1.0mm to 40mm|
|Length||5.8m, 6, Custom Lengths|
|Technology||Hot Rolled, Cold Finished, Heat Treated|
|Finish||Annealed & pickled, Bright Annealing, Polished|
|Test Certificate||EN 10204 3.1|
|Pipe Ends||Plain End, Bevel Ends|
|Packing||Plastic Plugs in Both Ends, Hexagonal Bundles of Max. 2,000kg with Several Steel Strips, Plastic End Caps|
Testing & Inspection of Stainless Steel Welded Pipes
Testing (Destructive, Non Destructive)
|Positive Material Identification – PMI Testing||Hydrostatic Test|
|Chemical Analysis – Spectro Analysis||Hydrogen-Induced Cracking (HIC) Test|
|Mechanical Testing Such as Tensile, Elongation, Reduction of Area||Sulfide Stress Corrosion Cracking (SSC), NACE TM 0177|
|Micro Test||Radiography Test|
|Macro Test||Dye Penetrant Test (DP Test)|
|Hardness Test||Ultra Sonic Test (UT)|
|Pitting Resistance Test||Eddy Current Testing|
|Intergranular Corrosion (IGC) Test||Impact Test|
|Flaring Test||Bend Test|
- Our internal inspection reports would be provided for all the goods before shipment.
- Buyers or their associates are most welcome to visit us for personal inspect
- We regularly have inspections ongoing at our premises from internationally acclaimed Inspection Agencies such as TUV, BVIS, SGS, Llyods, DNV etc.
Prices for Stainless Steel Welded Pipes
Prices for stainless steel welded pipes are directly co related to prices of the raw materials such as iron ore, metal scrap, chromium, nickel and various other alloying elements. The production cost of heat resistant stainless steel and nickel alloy plates is high as they contain high amount of nickel and chromium. Meanwhile, mild steel material is among the lowest cost steel available, followed by carbon steel, 400 series stainless steels, aluminium, alloy steel, and 300 series stainless steel. Special alloys such as titanium, Inconel, Monel and Hastelloy cost very high as the nickel, chromium and moly content is very high.
For special and discounted prices for various types of stainless steel welded pipes, please feel free to contact us through email, phone or whatsapp.
We are also regularly publishing our pricelist for various steel products on our blog.
Documents Provided at the time of Domestic Sales or Export of Stainless Steel Welded Pipes
|Certificate of Origin||Raw Material Test Reports|
|Commercial Invoice||Heat Treatment Charts|
|Packing List||Quality Assurance Plan (QAP)|
|Fumigation Certificates||NABL approved Laboratory Test Reports|
|Letter of Gurantee||Material Test Certificates|
|ROHS Certificate||Certificate of Compliance/Conformity|
Price Basis for Stainless Steel Welded Pipes
We can offer any of the following price basis depending on your requirement:
- FOR Site in India
- FOB Nhava Sheva
- CFR, CIF, CPT your destination port
- Door to Door Delivery Duty Paid as well as Duty Unpaid
Delivery Time of Stainless Steel Welded Pipes
- If the items are available in stock, we take 2 days from the date of receipt of advance payment to clear the shipment and send it to port.
- And in-case the items are not availabe in stock, the time taken for manufacturing depends on the size, quantity and grade.
- However we can claim the fact that we can compete with anyone in India on Delivery time and most of the time our production time is the least.
- We have tied up with strong logistic partners in India which can undertake any type of shipping activities and make sure that there is no delay in shipment.
Marking & Packing of Stainless Steel Welded Pipes
- All our products will have complete marking details which are co-related to the test certificates we supply.
- In case of orders for cut piece of Pipes, Sheets or Round Bars, the marking is transferred from the product from which it is cut. In such cases we provide Letter confirming the marking transfer and picture of the product from which it is cut.
- All goods are packed in wooden cases or pallets.
