ASTM A210 / ASME SA210 Grade A1 Seamless Tubes

ASTM A210 ASME SA210 Grade A1 Seamless Tubes

250.00

ASTM A210/ASME SA210 Grade A1 Seamless Medium-Carbon Steel Boiler and Superheater Tubes

If you are interested in purchasing high quality ASTM A210 Grade A1 seamless carbon steel boiler and superheater tubes, please contact us now for more detailed information. Email Us on sales@metallicametals.com | Call Us On +918928722715

  • ASTM A210/A210M, ASME SA210/SA210M Grade A1 Tubes Available for Sale in Size Range of  1⁄2 in. to 16 in. [12.7 to 406.4mm]. Tubes of other sizes are also available, but these tubes are to comply with all other requirements of this standard.
  • Specification: ASTM A210/ASME SA210 Standard Specification for Seamless Medium-Carbon Steel Boiler and Superheater Tubes
  • Mill test certificates will be issued according to EN10204.3.
  • When inserted in the boiler, tubes shall stand ex- panding and beading without showing cracks or flaws. When properly manipulated, superheater tubes shall stand all forging, welding, and bending operations necessary for application without developing defects.
  • ASTM A210 Grade A1 covers minimum-wall-thickness, seamless medium-carbon steel, boiler tubes and boiler flues, including safe ends, arch and stay tubes, and superheater tubes.

Metallica is one of the largest manufacturer and supplier of ASTM A210 Grade A1 seamless medium-carbon steel tubes in India. We offer ASTM A210 Grade A1 seamless tubes in size range of 1⁄2 in. to 16 in. [12.7 to 406.4mm], with wall thickness: 1.5mm-50mm in standard and custom lengths. As one of the most professional A210 Grade A1 seamless carbon steel tubes manufacturers and suppliers in India, we have one of the biggest steel pipe factory at your service. Metallica owns three warehouses, one factory and 3 offices mainly producing and marketing seamless carbon steel tube, alloy seamless steel tube, seamless & welded stainless steel tube, as well as nickel alloy tubes.

Why Buy ASTM A210 Grade A1 Superheater Seamless Steel Tube from Metallica Metals?

  • Large Scale Enterprise – Metallica is biggest stock holding, manufacturing and processing company of ASTM A210 carbon seamless tubes in India. Our large volume production, sales and purchase enables us to offer our products at the most competitive prices in the industry.
  • Testing of Carbon Steel Tubes – All ASTM A210 carbon seamless steel tubes are subjected to hydrostatic test, eddy current test, chemical and mechanical tests during the various stages of production.
  • Marking & Packing of ASTM A210 Carbon Steel Tubes – Marking on all pipes is as per the predefined rules in the specification.
  • Test Certificates & Inspection of ASTM A210 Carbon Steel Tubes – All our pipes are supplied with Mill test Reports, as per EN 10204 3.1. We can also allow third party inspection of all our products before delivery.
  • We have own QC team to control the quality to meet particular standard strictly
  • Short Lead Times – We can offer ASTM A210 carbon steel tubes with shortest delivery time.
  • We can produce either standard or non-standard of the carbon steel tube.

Related Key Words: boiler steel pipe, ASTM A210, ASME SA210, SA210A1, ASME SA210 / ASTM A210 boiler pipes, A210 pipes, A210 carbon steel tube, ASTM A210 seamless tubing, ASTM A210 carbon steel pipe, SA210 SEAMLESS PIPE, ASTM A210 cold drawn seamless steel tubes, ASTM A210 pipes and tubing, carbon steel tube, Seamless steel tube, steel tube.

Description

ASTM A210 Grade A1 Carbon Seamless Boiler Tubes Manufacturers

Metallica offers high quality of  ASTM A210/ASME SA210 Grade A1 boiler and superheater seamless steel tube to customers across the globe and in India. In addition to supplying ASTM A210 Grade A1 steel tubes, Metallica also offers fabrication services that include cutting, bending, shearing, saw cutting and welding for all of kinds of seamless steel pipes and tubes. Our primary objective is to ensure that our customers receive ASTM A210/ASME SA210 Grade C and Grade A1 tubes at competitive prices, together with excellent service.

Features of ASTM A210 Grade A1 Carbon Steel Boiler And Superheater Tubes

  • ASTM A210 Grade A1 carbon steel tubes shall be made by the seamless pipe making method, which can be hot-finished or cold-finished according to the specified requirements.
  • Hot-finished tubes need not be heat treated. Cold- finished tubes shall be given a subcritical anneal, a full anneal, or a normalizing heat treatment after the final cold finishing process.
  • Flattening Test – One flattening test shall be made on specimens from each end of one finished tube, not the one used for the flaring test, from each lot.
  • Flaring Test – One flaring test shall be made on specimens from each end of one finished tube, not the one used for the flattening test, from each lot.
  • Hardness Test – A Brinell or Rockwell hardness test is performed on an example of 2 tubes for every group. The term “batch” applies to all tubes of the same furnace, the same nominal diameter, and the same wall thickness before cutting. When the final heat treatment is carried out in a periodic furnace, a batch of all the tubes including only the same size and the same heat number are heat-treated under the same heat treatment furnace. When the final heat treatment is carried out in a continuous furnace, the batch includes the same dimensions, same calories, and all tubes with the same temperature, the same heating time and furnace speed in the same furnace. The tubes shall have a hardness not exceeding the following: 79 HRB or 143 HB for Grade A-1, 89 HRB or 179 HB for Grade C.
  • Hydrostatic or Nondestructive Electric Test – Each tube shall be subjected to the nondestructive electric test or the hydrostatic test. The type of test to be used shall be at the option of the manufacturer, unless otherwise specified in the purchase order.
  • Mechanical Test/Tension Test – One tension test shall be made on a specimen for lots of not more than 50 tubes. Tension tests shall be made on specimens from two tubes for lots of more than 50 tubes.

Production Range for ASTM A210 Grade A1 Carbon Steel Seamless Tubes

ProductASTM A210 Seamless Carbon Steel Tubes
SpecificationASTM A210
TypeSeamless
Size1⁄2 in. to 16 in. [12.7 to 406.4mm]
Production TypeHot finished and cold finished
Thickness1.5mm-50mm
GradeA1
LengthSingle random length/ Double random length or as customer’s actual request max length is 25 m
Surface QualityIf pickling or shot blasting or both are required, this shall be specifically stated in the order.
Test CertificatesMaterial Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2

Chemical Composition of ASTM A210 Grade A1 Carbon Steel Superheater Tubes

Chemical Components (%)
CMnSiPS
0.27 max0.93 max0.10 min0.035 max0.035 max

Mechanical Properties of ASTM A210 Grade A1 Carbon Steel Superheater Tubes

Tensile Strength (Mpa)Yield Strength (Mpa)Elongation (%)Hardness, HB
415 min255 min30 min143 max

Outside Diameter And Tolerance of ASTM A210 Grade A1 Carbon Steel Superheater Tubes

Hot rolledOutside Diameter, mmTolerance, mm
OD≤101.6+0.4/-0.8
101.6<OD≤127+0.4/-1.2
Cold DrawnOutside Diameter, mmTolerance, mm
OD<25.4±0.10
25.4≤OD≤38.1±0.15
38.1<OD<50.8±0.20
50.8≤OD<63.5±0.25
63.5≤OD<76.2±0.30
76.2≤OD≤101.6±0.38
101.6<OD≤127+0.38/-0.64

Wall Thickness & Tolerance of ASTM A210 Grade A1 Carbon Steel Superheater Tubes

Hot rolledOutside Diameter , mmTolerance, %
OD≤101.6, WT≤2.4+40/-0
OD≤101.6, 2.4<WT≤3.8+35/-0
OD≤101.6, 3.8<WT≤4.6+33/-0
OD≤101.6, WT>4.6+28/-0
OD>101.6, 2.4<WT≤3.8+35/-0
OD>101.6, 3.8<WT≤4.6+33/-0
OD>101.6, WT>4.6+28/-0
Cold DrawnOutside Diameter , mmTolerance, %
OD≤38.1+20/-0
OD>38.1+22/-0

Additional information

Specification

ASTM A210/ASME SA210 is the Standard Specification for Seamless Medium-Carbon Steel Boiler and Superheater Tubes

Type

Seamless

Size (OD)

1⁄2 in. to 16 in. [12.7 to 406.4mm]

Thickness

1.5mm-50mm

Length

Single random length/ Double random length or as customer’s actual request max length is 25 m

Certification

Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2

Delivery Condition

If pickling or shot blasting or both are required, this shall be specifically stated in the order.

Production Type

Hot finished and cold finished.
